Building a Multi-Container Docker Application: Web App + Database

In today’s development landscape, containerisation has become a cornerstone of modern application deployment. Docker, in particular, has revolutionised how we package, distribute, and run applications. In this post, I’ll walk you through creating a simple multi-container Docker application that demonstrates a common architectural pattern: a web application that writes to a separate database container.

The Project Goal

Our objective was straightforward: build two Docker containers with the following responsibilities:

Container 1: A basic web application that writes data to a database

Container 2: A database server that stores the data from the web application

https://github.com/xnomle/Docker-Application-Web-App-Database

Architecture Overview

The architecture consists of:

A Node.js/Express web application container exposing port 3000 A PostgreSQL database container exposing port 5432 A Docker network enabling communication between the containers A Docker volume providing data persistence for the database

Setting Up the Project Structure

Our project directory structure looks like this:

├── docker-compose.yml
├── webapp/
│   ├── dockerfile
│   ├── package.json
│   ├── app.js
│   └── public/
│       └── index.html
└── database/
    ├── Dockerfile
    └── init.sql

The Web Application Container

Our web application is a simple message board built with Node.js and Express. Users can post messages which are then stored in the database.

The core files include:

package.json:

json{
  "name": "simple-webapp",
  "version": "1.0.0",
  "description": "A simple web application that connects to a database",
  "main": "app.js",
  "dependencies": {
    "express": "^4.18.2",
    "pg": "^8.11.3",
    "body-parser": "^1.20.2"
  }
}

app.js:
javascriptconst express = require('express');
const { Pool } = require('pg');
const bodyParser = require('body-parser');

// Database connection
const pool = new Pool({
  user: process.env.DB_USER,
  host: process.env.DB_HOST,
  database: process.env.DB_NAME,
  password: process.env.DB_PASSWORD,
  port: process.env.DB_PORT,
});

// App setup and routes
// ...

dockerfile:

dockerfileFROM node:18-alpine

WORKDIR /app

# Copy app files explicitly
COPY package.json .
COPY app.js .
COPY public/ ./public/

RUN npm install

EXPOSE 3000

CMD ["node", "app.js"]

The Database Container

Our database container runs PostgreSQL and includes an initialisation script:

Dockerfile:

FROM postgres:15-alpine

# Copy initialisation scripts
COPY init.sql /docker-entrypoint-initdb.d/

# Expose PostgreSQL port
EXPOSE 5432

init.sql:

sql-- Create messages table
CREATE TABLE IF NOT EXISTS messages (
  id SERIAL PRIMARY KEY,
  content TEXT NOT NULL,
  created_at TIMESTAMP DEFAULT CURRENT_TIMESTAMP
);

-- Insert some initial data
INSERT INTO messages (content) VALUES
  ('Welcome to our simple message board!'),
  ('This is running on Docker containers');

Orchestrating with Docker Compose

Docker Compose makes it easy to define and run multi-container applications. Our docker-compose.yml file:

services:
  webapp:
    build:
      context: ./webapp
      dockerfile: dockerfile
    ports:
      - "3000:3000"
    environment:
      - DB_HOST=database
      - DB_USER=postgres
      - DB_PASSWORD=postgres
      - DB_NAME=myapp
      - DB_PORT=5432
    depends_on:
      - database
    networks:
      - app-network

  database:
    build:
      context: ./database
      dockerfile: Dockerfile
    ports:
      - "5432:5432"
    environment:
      - POSTGRES_USER=postgres
      - POSTGRES_PASSWORD=postgres
      - POSTGRES_DB=myapp
    volumes:
      - db-data:/var/lib/postgresql/data
    networks:
      - app-network

volumes:
  db-data:

networks:
  app-network:
    driver: bridge

Key elements in this configuration:

  1. Environment Variables: We pass database credentials to both containers
  2. depends_on: Ensures the database container starts before the web app
  3. networks: Creates a private network for container communication
  4. volumes: Provides data persistence for the database

Lessons Learned and Best Practices

During development, we encountered and fixed several issues:

  1. Database Connection Timing The web application needs to wait for the database to be ready before connecting. We implemented a retry mechanism in our code:
async function initialiseDb() {
  try {
    // Connection code
  } catch (err) {
    // Retry after a delay
    setTimeout(initialiseDb, 5000);
  }
}

Deployment

To deploy this application, you simply run:

docker-compose up

This single command builds the images (if needed), creates the containers, networks, and volumes, and starts all services.

Conclusion

This multi-container setup demonstrates several important concepts in Docker orchestration:

  1. Separation of concerns: Keeping application and database in separate containers
  2. Networking: Allowing containers to communicate while remaining isolated
  3. Environment configuration: Using environment variables for container configuration
  4. Data persistence: Using volumes to persist database data

This project serves as an excellent starting point for microservice architectures. The principles shown here—container communication, environment configuration, and data persistence—are fundamental to containerised application development.
